0811-2X6R-28-F

Conn RJ-45 Integrated Magnetics RCP 96 POS 2.54mm Solder RA Thru-Hole 96 Terminal 12 Port Tray

Thumbnail 0811-2X6R-28-F Thumbnail 0811-2X6R-28-F
廠商型號: 0811-2X6R-28-F
芯天下內部編號: 13-0811-2X6R-28-F
生產廠商:
bel bel
描述: Conn RJ-45 Integrated Magnetics RCP 96 POS 2.54mm Solder RA Thru-Hole 96 Terminal 12 Port Tray
產品類別: Interconnect|Connector Telephone and Telecom
客戶編號:
規格書: 查看PDF
瀏覽次數: 1

所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。

庫存與訂購

庫存: 0
庫存獲取中，請稍候....

產品參數

參數類型 參數值
Type RJ-45 Integrated Magnetics
Gender RCP
Pitch 2.54 mm
Termination Method Solder
Mounting Through Hole
Body Orientation Right Angle
Standard Package Trays
Number of Rows 2
Tab Direction Up and Down
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Mounting Type Through Hole
Number of Ports 12
Shield Material Copper Alloy
Features Board Guide
Connector Type RJ45
Contact Finish Gold
Packaging Tray
Applications 10/100 Base-TX, AutoMDIX
LED Color Does Not Contain LED
Height Above Board 1.004" (25.50mm)
Number of Cores per Jack 4
Termination Solder
Contact Finish Thickness 30μin (0.76μm)
Housing Material Polybutylene Terephthalate (PBT)
rohs Lead free / RoHS Compliant
