1-6609031-7
Power Line Filter 50Hz/60Hz 20A 250VAC Faston Flange Mount
1-Top.jpg)
廠商型號:
1-6609031-7
芯天下內部編號:
35-1-6609031-7
生產廠商:
te connectivity / corcom
描述:
Power Line Filter 50Hz/60Hz 20A 250VAC Faston Flange Mount
產品類別:
Filter|Power Line Filter
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Family | 6609031 |
| Maximum Current Rating | 20 A |
| Maximum Voltage Rating | 250 Vac |
| Operating Frequency | 50|60 Hz |
| Termination | Faston |
| Minimum Operating Temperature | -10 °C |
| Maximum Operating Temperature | 40 °C |
| Mounting | Flange Mount |
| Standard Package | Bulk |
| Voltage - Rated AC | 250V |
| Mounting Type | Chassis |
| Approvals | CSA, UL, VDE |
| Termination Style | Quick Connect |
| Current | 20A |
| Applications | General Purpose |
| Operating Temperature | -10°C ~ 40°C |
| Filter Type | Single Phase |
| Configuration | Two Stage |
| Frequency - Operating | 50 ~ 60Hz |
| rohs | Lead free / RoHS Compliant |
| Leakage Current (Max) (250VAC, 50Hz)?(mA) | .36 |
| Ground Choke Option | No |
| 電壓（最大值）?(VAC) | 250 |
| Leakage Current (Max) (120VAC, 60Hz)?(mA) | .21 |
| 安裝方式 | 帶凸緣 |
| 額定電流?(A) | 20 |
| Input Type | .250" FASTON |
| 濾波器類型 | 電源線 |
| Filtered | Yes |
| 輸出類型 | 250 快速連接端子 |
| 工作溫度范圍?(°C) | -10 – 40 |
