101-1158
Development Boards & Kits - Other Processors RCM4100 Analog Dev Kit (Intl)
廠商型號:
101-1158
芯天下內部編號:
307-101-1158
生產廠商:
Rabbit Semiconductor

描述:
Development Boards & Kits - Other Processors RCM4100 Analog Dev Kit (Intl)
產品類別:
Embedded Solutions|Engineering Tools|Embedded Processor Development Tools|Development Boards & Kits - Other Processors
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
參數類型 | 參數值 |
---|---|
Product Category | Development Boards & Kits - Other Processors |
RoHS | No |
Interface Type | SPI |
Data Bus Width | 8 bit |
Type | MPU Module |
For Use With/Related Products | RCM4100 |
Contents | RabbitCore Module, Dev. Board, AC Adapter, Cable and Dynamic C? CD-Rom |
Standard Package | 1 |
rohs | Lead free / RoHS Compliant |
Core Processor | Rabbit 4000 |
Dimensions | 36 x 48 x 12mm |
Height | 12mm |
Included Features | Analogue to Digital Converter, Input Capture, Pulse Width Modulator, Quadrature Decoder, Real Time Clock, Slave Interface, Timers, Watchdog/Supervisor |
Kit Includes | Backup Battery, Core Module |
Kit Type | Intelligence & Control |
Length | 48mm |
Maximum Operating Temperature | +85°C |
Minimum Operating Temperature | -40°C |
Processor Clock Speed | 59MHz |
Supported Bus Interfaces | Asynch, IrDA, SDLC, SPI |
Supported I/O Interfaces | GPIO, Parallel |
Width | 36mm |
Silicon Manufacturer | :Rabbit Semiconductor |
Core Architecture | :RCM4100 |
Core Sub-Architecture | :RCM4100 |
Silicon Core Number | :AT58206-UL1T |
Silicon Family Name | :RabbitCore |
Kit Contents | :Board |
Features | :Auxiliary I/O Feature, Reducing Processor Bus Loading, Low-Power Modes |
Development Tool Type | :Development Kit |
Kit Contents Descriptive | :RabbitCore RCM4100 module, Prototyping board, accessory parts and all development tools |
Kit Features | :Rabbit 4000 Microprocessor, 58.98MHz, CMOS-compatible Serial Ports, 512K Flash, 256K/512K Data SRAM |
MCU Supported Families | :RabbitCore |
Plug Type | :Euro, UK, US |
Supported Devices | :RCM4100 |
Weight (kg) | 0.75 |
Tariff No. | 84733080 |
