2035-09-BLF
MINI GAS DISCHARGE TUBE,2-POLE,90V,4MM,BULK,HAZMAT
廠商型號:
2035-09-BLF
芯天下內部編號:
18-2035-09-BLF
生產廠商:
bourns
描述:
MINI GAS DISCHARGE TUBE,2-POLE,90V,4MM,BULK,HAZMAT
產品類別:
Interconnect|Connector Circular
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Product Category | Gas Discharge Tubes - GDTs / Gas Plasma Arrestors |
| RoHS | RoHS Compliant |
| DC Breakover Voltage (Nominal) | 90 V |
| Series | 2035 |
| Termination Style | Axial |
| Packaging | Bulk |
| Dimensions | 5 mm D x 4 mm L |
| Factory Pack Quantity | 100 |
| Lead Diameter | 0.8 |
| Typical AC Discharge Current@1s@ | 10 |
| Mounting | Through Hole |
| Maximum Capacitance@1MHz | 1 |
| Typical Impulse Life@10/1000us | 300 |
| Typical DC Sparkover Voltage@100V/s | 90 |
| Failsafe Protection | No |
| EU RoHS | Compliant |
| Minimum Operating Temperature | -55 |
| Product Length | 4.1 |
| Maximum Operating Temperature | 85 |
| Maximum DC Holdover Voltage | 52@150ms |
| Maximum Impulse Sparkover Voltage@100V/s | 300 |
| Typical Impulse Discharge Current@8/20us@10Times | 10 |
| Minimum Insulation Resistance@100V | 10 |
| Maximum Impulse Sparkover Voltage@1KV/s | 550 |
| Product Depth | 5 |
| Number of Terminals | 2 |
| DC Sparkover Voltage Tolerance | ±20% |
| Number of Electrodes | 2 |
| Product Height | 5 |
| Agency Approvals | UL |
| Current - AC Discharge (Nom) | 5A |
| Impulse Discharge Current (8/20us) | 5.0kA |
| Mounting Type | Through Hole |
| Fail Short | No |
| Number of Poles | 2 |
| Voltage - DC Spark Over (Nom) | 90V |
| Standard Package | 100 |
| Tolerance | ±20% |
| Other Names | 203509BLF |
| Package/Case | Axial Cylinder |
| rohs | Lead free / RoHS Compliant |
| Length | 9.5mm |
| Maximum Operating Temperature | +155°C |
| Minimum Operating Temperature | -55°C |
| Mounting Style | Through Hole |
| Operating Temperature Max Deg. C | 85C |
| Operating Temperature Min Deg. C | -55C |
| Product Length (mm) | 4.1 mm |
| Product Depth (mm) | 5 mm |
| Product Height (mm) | 5 mm |
| DC Sparkover Voltage (Typ)@100V/s | 90 |
| Impulse Sparkover Voltage (Max)@100V/s | 300 |
| Impulse Sparkover Voltage (Max)@1KV/s | 550 |
| DC Holdover Voltage (Max) | 52@150ms |
| Impulse Discharge Current (Typ)@8/20us@10Times | 10 |
| Capacitance (Max)@1MHz | 1 |
| DC Breakover Voltage | :90V |
| Impulse Discharge Current | :10kA |
| Impulse Sparkover Voltage | :550V |
| GDT Case Style | :Axial Leaded |
| SVHC | :No SVHC (16-Dec-2013) |
| Weight (kg) | 0.01 |
| Tariff No. | 85354000 |
| Brand/Series | 2035Series |
| Capacitance | 1pF |
| Current,ACFollow | 5A |
| Current,Surge | 10kA |
| Package | Metal |
| Temperature,Operating,Maximum | 85°C |
| Temperature,Operating,Minimum | -55°C |
| Type | GDT |
| Voltage,Breakdown | 550V |
| Voltage,DCHoldover | 52V |
| Voltage,DCSparkover | 90V |
