39208000000
Fuses 250V IEC TL LL .800A TE5
廠商型號:
39208000000
芯天下內部編號:
206-39208000000
生產廠商:
Littelfuse
描述:
Fuses 250V IEC TL LL .800A TE5
產品類別:
Circuit Protection|Fuses & Fuse Holders|Fuses
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Product Category | Fuses |
| RoHS | RoHS Compliant |
| Product | Specialty Fuses |
| Product Type | PCB Mount Fuse |
| Body Style | Leaded Fuses |
| Current Rating | 800 mA |
| Voltage Rating AC | 250 V |
| Fuse Type | Time Delay / Slow Blow |
| Fuse Size / Group | TE5 |
| Dimensions | 8.5 mm L x 8 mm W |
| Mounting Style | Through Hole |
| Termination Style | Radial |
| Series | 392 |
| Body Material | Thermoplastic |
| Case Height | 4 mm |
| Case Length | 8.5 mm |
| Case Width | 8 mm |
| Indicator Style | Without Indicator |
| Operating Temperature Range | - 40 C to + 85 C |
| Packaging | Ammo Pack |
| Factory Pack Quantity | 1400 |
| Type | PCB Mount Fuse |
| Voltage Rating | 250 V |
| Product Length | 8.5 |
| EU RoHS | Compliant |
| Maximum Operating Temperature | 85 |
| Product Depth | 4(Max) |
| Mounting | Through Hole |
| Number of Terminals | 2 |
| Maximum AC Voltage Rating | 250 |
| Fuse Material | Thermoplastic |
| Acting | Slow Blow |
| Maximum Power Dissipation | 0.28 |
| Current Rating | 0.8 |
| Minimum Operating Temperature | -40 |
| Product Height | 8(Max) |
| Unit Pack | 0 |
| MOQ | 1 |
| Breaking Capacity @ Rated Voltage | 25A |
| Mounting Type | Through Hole |
| Voltage Rating - AC | 250V |
| Approvals | CQC, cULus, KC, SEMKO, VDE |
| Size / Dimension | 0.335" L x 0.157" W x 0.315" H (8.50mm x 4.00mm x 8.00mm) |
| Operating Temperature | -40°C ~ 125°C |
| Standard Package | 1,400 |
| Response Time | Slow |
| DC Cold Resistance | 0.096 Ohm |
| Melting I2t | 3.8 |
| Package/Case | Radial, Box |
| rohs | Lead free / RoHS Compliant |
| Other Names | F5498CT |
| Voltage Rating VAC | :250V |
| Fuse Current | :800mA |
| Breaking Capacity | :25A @ 250VAC |
| Blow Characteristic | :Time Delay |
| Fuse Case Style | :Radial Leaded |
| Fuse Mounting | :Through Hole |
| Weight (kg) | 0 |
| Tariff No. | 85361010 |
