5019203001
Conn Board to Board HDR 30 POS 0.5mm Solder ST SMD T/R
廠商型號:
5019203001
芯天下內部編號:
256-5019203001
生產廠商:
molex
描述:
Conn Board to Board HDR 30 POS 0.5mm Solder ST SMD T/R
產品類別:
Interconnect|Connector Headers and PCB Receptacles
客戶編號:
規格書:
查看PDF
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Type | Board to Board |
| Pitch | 0.5 mm |
| Number of Rows | 2 |
| Number of Contacts | 30 |
| Gender | HDR |
| Contact Plating | Gold |
| Termination Method | Solder |
| Standard Package | Cut Tape |
| Packaging | Tape and Reel |
| Product Length | 9.8 |
| EU RoHS | Compliant |
| Product Depth | 3.1 |
| Mounting | Surface Mount |
| Body Orientation | Straight |
| Maximum Voltage Rating | 50VAC |
| Product Height | 3.42 |
| Housing Material | Thermoplastic |
| Pitch | 0.5 |
| Housing Color | Black |
| Maximum Current Rating | 0.5/Contact |
| Contact Material | Brass |
| Number of Positions | 30 |
| Mounting Type | Surface Mount |
| Connector Type | Plug, Outer Shroud Contacts |
| Contact Finish | Gold |
| Height Above Board | 0.135" (3.43mm) |
| Mated Stacking Heights | 4mm |
| Other Names | 501920-3001 |
| rohs | Lead free / RoHS Compliant |
| Connector type | female |
| Height | 4mm |
| Gross weight | 0.25 g |
| Number of pins | 30 |
| Multiplicity | 1500 |
| Contacts pitch | 0.5mm |
