59025-040
SENSOR MAGNETIC SPST-NC .25A
廠商型號:
59025-040
芯天下內部編號:
154-59025-040
生產廠商:
Hamlin Inc
描述:
SENSOR MAGNETIC SPST-NC .25A
產品類別:
Sensors, Transducers|Magnetic Sensors - Position, Proximity, Speed (Modules)|59025
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Subcategory | Proximity Sensor |
| Lead Time | 70 Days |
| Function | Switch |
| Must Operate | 3.81mm |
| Type | Reed Switch |
| Termination Style | Wire Leads |
| Output Type | SPST-NC |
| Standard Package | 50 |
| Must Release | 20.32mm |
| Actuator Material | Magnet |
| Package/Case | Probe |
| rohs | Lead free / RoHS Compliant |
| RoHS | RoHS Compliant |
| Switching Power (Max) | 5W |
| Carry Current | 1.5 Amps |
| Activate Distance | .216" (5.5mm) |
| Mounting Type | Free Hanging (In-Line) |
| Terminaion Style | Wire Leads |
| Switching Voltage (DC) (Max) | 175V |
| Max Switching Voltage | 175 VDC |
| MainCategory | Sensors |
| Magnet | Specified, Not Included |
| Circuit | SPST-NC |
| Termination | Leads |
| Switching Current (DC) (Max) | 250mA |
| Contact Configuration | 1B SPST-NO |
| SubCategory | Reed Sensor |
