66100-9
Contact SKT Crimp ST Cable Mount Strip
廠商型號:
66100-9
芯天下內部編號:
35-66100-9
生產廠商:
te connectivity / amp
描述:
Contact SKT Crimp ST Cable Mount Strip
產品類別:
Interconnect|Connector Contacts
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Connector Type | Connector Power |
| Contact Type | Power |
| Contact Material | Brass |
| Contact Plating | Gold Over Nickel |
| Gender | SKT |
| Termination Method | Crimp |
| Standard Package | Tape & Reel |
| RoHSELV Compliance | RoHS compliant, ELV compliant |
| Wire Range (mm AWG) | 0.80-1.40?2 [18-16] |
| Contact Size | 16 |
| Grade | Commercial |
| Pin Diameter (mm in) | 1.57 [0.062] |
| PinSocket | Socket |
| Wire Termination Type | Crimp |
| Insulation Diameter (mm in) | 2.03 a?? 2.54 [0.080 a?? 0.100] |
| Termination End Plating | Gold Flash |
| Used With | G Series Connectors, CPC Connectors, M Series Connectors |
| Spring Material | Stainless Steel |
| Contact Mating Area Plating Material | Gold (30) over Nickel (50) |
| High Current | No |
| WireCable Type | Discrete Wire |
| Insulation Support | Yes |
| Product Type | Type III+ |
| Plating | Gold |
| Wire Gauge | 16-18 AWG |
| Material | Brass |
| Packaging | Tape & Reel (TR) |
| Plating - Thickness | 30μin (0.76μm) |
| Pin or Socket | Socket |
| Type | Stamped |
| Contact Termination | Crimp |
| rohs | Lead free / RoHS Compliant |
| Mounting Type | Cable Mount |
| Factory Pack Quantity | 4000 |
| Product Category | Standard Circular Contacts |
| Current Rating | 13 A |
| Series | Multimate Type III |
| Contact Gender | Socket (Female) |
| Tradename | Multimate |
| RoHS | RoHS Compliant |
| For Use With | :G Series, M Series & CPC Series Connectors |
| Wire Size AWG Min | :18AWG |
| Wire Size AWG Max | :16AWG |
| Wire Size (AWG) | :18AWG to 16AWG |
| Wire Size Range (AWG) | :18-16 |
| Weight (kg) | 0.381 |
| Tariff No. | 85366990 |
