70M-ODC5B
OptoCoupler Transistor-Out 1-CH 5-Pin
廠商型號:
70M-ODC5B
芯天下內部編號:
153-70M-ODC5B
生產廠商:
grayhill
描述:
OptoCoupler Transistor-Out 1-CH 5-Pin
產品類別:
Switches and Relays|Relays|Solid State Relay
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Mounting | Screw |
| Standard Package | Bulk |
| Maximum Load Voltage | 60VDC |
| Maximum Load Current | 3A |
| EU RoHS | RoHS Not Applicable |
| Maximum Operating Temperature | 100 |
| Module Type | Output Module |
| Output Type | DC |
| Terminal Type | PC Pins |
| Agency Approvals | CE/CSA/TUV/UL |
| Input Type | DC |
| Minimum Operating Temperature | -40 |
| I/O Isolation Voltage | 4000Vrms |
| Maximum Input Voltage | 60VDC |
| Minimum Load Voltage | 3VDC |
| Technology | Solid State |
| Subcategory | I/O Module |
| Series | 70 |
| Lead Time | 21 Days |
| Style | Mini |
| Color | Red |
| Current - Input | 14mA |
| Voltage - Output | 3 ~ 60VDC |
| Current - Output | 0.02 ~ 3A |
| Turn On Time | 0.075ms |
| Turn Off Time | 0.50ms |
| Type | DC |
| Voltage - Input | 5VDC (2.5 ~ 10VDC) |
| rohs | Contains lead / RoHS non-compliant |
| ConnectiontoHost | BoardMount |
| Current,Input | 14mA |
| NumberofChannels | 1 |
| Output | 3to60VDC |
| OutputType | Digital |
| Output,Range | 3to60VDC |
| PrimaryType | Control |
| SpecialFeatures | OpticalIsolation |
| Voltage,Isolation | 4000VAC |
| Voltage,Supply | 5VDC |
| 接通時間 | 0.075ms |
| 系列 | 70 |
| 電流 - 輸出 | 0.02 ~ 3A |
| 樣式 | Mini |
| 電壓 - 輸出 | 3 ~ 60VDC |
| 關斷時間 | 0.50ms |
| 電壓 - 輸入 | 5VDC (2.5 ~ 10VDC) |
| 類型 | DC |
| 顏色 | Red |
| 電流 - 輸入 | 14mA |
