B82722A2301N001

Epcos 47mH ±30% Ferrite, 0.3A Idc, 2500mΩ Rdc

Thumbnail B82722A2301N001 Thumbnail B82722A2301N001 Thumbnail B82722A2301N001
廠商型號: B82722A2301N001
芯天下內部編號: 125-B82722A2301N001
生產廠商:
Epcos Epcos
描述: Epcos 47mH ±30% Ferrite, 0.3A Idc, 2500mΩ Rdc
產品類別: Passive Components|Inductors|Leaded Inductors
客戶編號:
規格書: 查看PDF

所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。

庫存與訂購

庫存: 0
庫存獲取中，請稍候....

產品參數

參數類型 參數值
Core Material Ferrite
Depth 22.7mm
Dimensions 22.3 x 22.7 x 13.3mm
Height 13.3mm
Inductance 47 mH
Lead Diameter 0.7mm
Lead Pitch 12.5 mm, 20 mm
Length 22.3mm
Maximum DC Current 0.3A
Maximum DC Resistance 2500mΩ
Maximum Operating Temperature +125°C
Minimum Operating Temperature -40°C
Tolerance ±30%
Product Range :EPCOS - B82722A Series
Rated Current :300mA
SVHC :No SVHC (20-Jun-2013)
DC Current Max :300mA
DC Current Rating :300mA
DC Resistance Max :2.5ohm
Inductance Tolerance :± 30%
Inductor Case Style :Through Hole
Inductor Type :Power Line Choke
No. of Pins :4
Weight (kg) 0.026
Tariff No. 85045095
