CB1A-M-12V
Automotive Relays 40A 12VDC 1 FORM A BRACKET
廠商型號:
CB1A-M-12V
芯天下內部編號:
282-CB1A-M-12V
生產廠商:
Panasonic Electric Works
描述:
Automotive Relays 40A 12VDC 1 FORM A BRACKET
產品類別:
Electromechanical|Relays|Automotive Relays
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Product Category | Automotive Relays |
| RoHS | RoHS Compliant By Exemption |
| Contact Form | 1 Form A (SPST-NO) |
| Contact Current Rating | 40 A |
| Coil Voltage | 12 VDC |
| Coil Resistance | 103 Ohms |
| Coil Current | 117 mA |
| Mounting Style | Panel |
| Contact Material | Silver Alloy |
| Coil Termination | Clip |
| Coil Type | Standard |
| Contact Termination | Clip |
| Packaging | Bulk |
| Power Consumption | 1400 mW |
| Factory Pack Quantity | 50 |
| Type | Automotive Relays |
| Relay Construction | Non-Latching |
| Coil Suppression Diode | No |
| Mounting | Bracket Mount |
| Termination Style | 0.25Quick Connect |
| Maximum Current Rating | 40 |
| Maximum DC Voltage Rating | 14 |
| Minimum Dropout Voltage | 4.2VDC |
| Coil Current | 117 |
| Contact Arrangement | SPST-NO |
| Push to Test Button | No |
| Minimum Operating Temperature | -40 |
| Product Length | 30 |
| Maximum Operating Temperature | 85 |
| Maximum Power Rating | 1.4W |
| EU RoHS | Compliant |
| Coil Resistance | 103 |
| Operate Time | 15 |
| DC Coil Voltage | 12 |
| Product Depth | 22 |
| Number of Terminals | 4 |
| Product Height | 52 |
| Seal | Sealed |
| Maximum Pick-Up Voltage | 7VDC |
| LED Indicator | No |
| Turn On Voltage (Max) | 7 VDC |
| Features | Sealed - Fully |
| Turn Off Voltage (Min) | 1.2 VDC |
| Coil Power | 1.4 W |
| Relay Type | Automotive |
| Switching Voltage | 14VDC - Nom |
| Release Time | 15ms |
| Operating Temperature | -40°C ~ 85°C |
| Operate Time | 15ms |
| Contact Rating (Current) | 40A |
| Standard Package | 50 |
| Mounting Type | Chassis Mount |
| rohs | Lead free / RoHS Compliant |
| Brand/Series | CBSeries |
| ContactForm | SPST-NO |
| CurrentRating | 40A |
| Current,Rating | 40A |
| Function | Automotive |
| MountingType | Bracket |
| RelayType | ElectroMechanical |
| Voltage,Control | 12VDC |
| Voltage,Rating | 14VDC |
| Operating Function | Single Side Stable |
| Protective element | None |
| SubCategory | Automotive Relay |
| Protective construction | Sealed type |
| Heat resistant of types | Standard type |
| MainCategory | Relays |
| Current | 40 Amps |
| Contact Configuration | 1A SPST-NO |
| 導通電壓（最大值） | 7 VDC |
| 關閉電壓（最小值） | 1.2 VDC |
| 繼電器類型 | Automotive |
| 開關電壓 | 14VDC - Nom |
| 額定接觸（電流） | 40A |
| 線圈電壓 | 12VDC |
| 釋放時間 | 15ms |
| 線圈類型 | Non Latching |
| 接觸點外形 | SPST-NO (1 Form A) |
| 線圈電流 | 117mA |
| 工作時間 | 15ms |
| 線圈電阻 | 103 Ω |
| 壽命 | 10 ^6（機械）次操作，10^5（電氣）次操作 |
| 線圈功率 | 1.4W |
| 最大切換電壓 直流 | 14V |
| 長度 | 26mm |
| 最大工作溫度 | +85°C |
| 線圈對觸點絕緣 | 500V rms |
| 端子類型 | 印刷電路板引腳 |
| 高度 | 25mm |
| 觸點配置 | 單極常開 |
| 安裝類型 | 法蘭安裝 |
| 工作溫度范圍 | -40 → +85°C |
| 最大切換電流 直流 | 40 A |
| 尺寸 | 26 x 22 x 25mm |
| 觸點材料 | 金合金 |
| 深度 | 22mm |
| Board Level Components | Y |
| 應用類型 | 農業設備，汽車 |
| 最小工作溫度 | -40°C |
