G3VM-21LR
Solid State Relays - PCB Mount 20V, SPST-NO, SSOP4 SMT 160mA, 5ohm, 1pF
廠商型號:
G3VM-21LR
芯天下內部編號:
232-G3VM-21LR
生產廠商:
Omron Electronics
描述:
Solid State Relays - PCB Mount 20V, SPST-NO, SSOP4 SMT 160mA, 5ohm, 1pF
產品類別:
Optoelectronics|Optocouplers / Photocouplers|Solid State Relays|Solid State Relays - PCB Mount
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Product Category | Solid State Relays - PCB Mount |
| RoHS | RoHS Compliant |
| Control Voltage Range | 1 V to 1.3 V |
| Load Voltage Rating | 20 V |
| Load Current Rating | 160 mA |
| Contact Form | 1 Form A (SPST-NO) |
| Output Device | MOSFET |
| Package / Case | SSOP-4 |
| Mounting Style | SMD/SMT |
| Product Type | PCB Mount |
| Series | G3VM |
| Factory Pack Quantity | 1 |
| Termination Style | Solder Tab |
| Part # Aliases | G3VM21LRNC |
| Relay Type | Relay |
| Mounting Type | Surface Mount |
| Load Current | 160mA |
| Voltage - Load | 0 ~ 20 V |
| Supplier Device Package | 4-SSOP |
| Output Type | AC, DC |
| Packaging | Tube |
| On-State Resistance | 8 Ohm |
| Circuit | SPST-NO (1 Form A) |
| Standard Package | 1 |
| Voltage - Input | 1.15VDC |
| Package/Case | 4-SMD (0.165", 4.20mm) |
| rohs | Lead free / RoHS Compliant |
| CAD Drawing | 3D CAD Model |
| Depth | 3.5mm |
| Height | 1.8mm |
| Length | 2.04mm |
| Maximum Control Voltage | 1.3 V |
| Maximum Load Current | 0.16 A |
| Maximum Load Voltage | 20 V |
| Minimum Load Current | 160 mA |
| Input Current | 4 mA |
| Load Voltage Max | :20VAC |
| On State Resistance Max | :8ohm |
| Contact Configuration | :SPST-NO |
| Isolation Voltage | :1.5kV |
| Forward Current If | :30mA |
| Relay Terminals | :SMD |
| SVHC | :No SVHC (20-Jun-2013) |
| Control Voltage DC Max | :1.3V |
| Control Voltage DC Min | :1V |
| Dielectric Strength Voltage Vrms | :1500V |
| Turn Off Time | :0.12ns |
| Turn On Time | :0.06μs |
| Weight (kg) | 0.00003 |
| Tariff No. | 85364900 |
| Capacitance | 2.5pF |
| ContactForm | SPST-NO |
| CurrentRating | 0.160A |
| Current,Leakage | 1nA |
| Current,Rating | 160mA |
| Function | General-Purpose |
| MountingType | SMD |
| NumberofPins | 4 |
| Package | SOP-4 |
| RelayType | MOSFET |
| Standards | UL,RoHS |
| Termination | SurfaceMount |
| Voltage,Rating | 20V |
| Case | SSOP4 |
| Relay type | solid state |
| Operating current max | 160mA |
| Multiplicity | 1 |
| Contacts configuration | SPST-NO |
| Release time | 0.12ms |
| Control current | 30mA |
| Gross weight | 0.11 g |
| Operating temperature | -20...85°C |
| Operate time | 0.06ms |
| Mounting | SMT |
| Relay variant | 1-phase, MOSFET |
| Relay series | G3VM |
| Switched voltage | max 20V DC, max 20V AC |
