HC2E-HP-DC24V
General Purpose Relays 2 Form C 24VDC Amber Relay PCB Type
廠商型號:
HC2E-HP-DC24V
芯天下內部編號:
282-HC2E-HP-DC24V
生產廠商:
Panasonic Electric Works
描述:
General Purpose Relays 2 Form C 24VDC Amber Relay PCB Type
產品類別:
Electromechanical|Relays|General Purpose Relays
客戶編號:
規(guī)格書:
查看PDF
所示圖像僅為示意圖。請從產品數據表中獲得準確的規(guī)格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Product Category | General Purpose Relays |
| RoHS | RoHS Compliant |
| Packaging | Bulk |
| Factory Pack Quantity | 20 |
| Life | Obsolete |
| Relay Construction | Non-Latching |
| Coil Suppression Diode | No |
| Mounting | Through Hole |
| Termination Style | PC Pin |
| Maximum Current Rating | 2DC|3AC |
| Maximum DC Voltage Rating | 30 |
| Minimum Dropout Voltage | 2.4VDC |
| Type | Miniature Relay |
| Coil Current | 37 |
| Contact Arrangement | DPDT |
| Push to Test Button | No |
| Package Type | Dust Cover |
| Minimum Operating Temperature | -40 |
| Product Length | 27.2 |
| Maximum Operating Temperature | 60 |
| Maximum Power Rating | 700VA |
| Contact Form | 2 Form C |
| EU RoHS | Compliant |
| Coil Resistance | 650 |
| Operate Time | 20 |
| DC Coil Voltage | 24 |
| Product Depth | 20.8 |
| Number of Terminals | 8 |
| Maximum AC Voltage Rating | 250 |
| Product Height | 35.2 |
| Seal | Sealed |
| Maximum Pick-Up Voltage | 19.2VDC |
| LED Indicator | No |
| Contact Material | Silver Cadmium Oxide |
| Coil Current | 37mA |
| Coil Voltage | 24VDC |
| Turn On Voltage (Max) | 19.2 VDC |
| Features | Sealed - Amber |
| Coil Type | Non Latching |
| Turn Off Voltage (Min) | 2.4 VDC |
| Coil Power | 900 mW |
| Relay Type | General Purpose |
| Switching Voltage | 250VAC - Max |
| Release Time | 5ms |
| Operating Temperature | -40°C ~ 60°C |
| Operate Time | 10ms |
| Contact Rating (Current) | 3A |
| Standard Package | 20 |
| Mounting Type | Through Hole |
| Coil Resistance | 650 Ohms |
| rohs | Lead free / RoHS Compliant |
| Ambient air pressure | 760 mmHg +20% (1.013 mb +20%) |
| Min switching capacity | 1 mA, 100 mV DC |
| SubCategory | General Purpose Relay |
| Operating Function | Single Side Stable |
| Max switching power | 700 VA |
| Max switching current | 3 A |
| Max switching voltage | 250 V AC |
| Release time | Max. 20 ms |
| Contact Configuration | 2C DPDT |
| Current | 7 Amps |
| Operate time | Max. 20 ms |
| Nominal switching capacity | 3 A 250 V AC |
| Type classifications | Standard |
| MainCategory | Relays |
| Humidity | 5 to 85% R.H. |
| Ambient temp | 40C to +60C 40F to +140F |
