KAR08LGGT
DIP Switches / SIP Switches DIP
廠商型號:
KAR08LGGT
芯天下內部編號:
129-KAR08LGGT
生產廠商:
E-Switch
描述:
DIP Switches / SIP Switches DIP
產品類別:
Switches|DIP Switches|KAR
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Washable | Yes |
| Actuator Type | Piano |
| Mounting Type | Surface Mount |
| Number of Positions | 8 |
| Circuit | SPST |
| Standard Package | 23 |
| Contact Rating @ Voltage | 0.025A @ 24VDC |
| Orientation | Side Actuated |
| Other Names | EG4482 |
| Actuator Level | Raised |
| Contact Resistance | Initial: 50 milliohms max, After Life: 100 milliohms max |
| Terminal Finish | Gold |
| Operating Force | 500gf max |
| SubCategory | DIP Switch |
| Terminal Contacts | Brass with PACKAGING gold over tin plate |
| Ratings | 25 mA @ 24 VDC |
| Base & Cover | PPS, UL94-V0 |
| Dielectric Strength | 500 VAC for 60 seconds |
| MainCategory | Switches |
| Packaging | Standard Tube Qty |
| Movable Contacts | Copper alloy with gold over tin plate |
| Operating Temp | -30C to +85C |
| Insulation Resistance | 1,000 Megaohms min @ 100VDC |
| Storage Temperature | -40C to +85C |
| Termination | Gull Wing |
| Actuator | Nylon, UL94-V0 |
| Mechanical Life | 2000 make-and-break cycles, each circuit |
| Type | Piano DIP / Low Profile |
| Actuator L Dimension | Extended |
