PARS433.92K04R
IC RESONATOR 433.92MHZ 3.2PF SMD T/R
廠商型號:
PARS433.92K04R
芯天下內部編號:
10-PARS433-92K04R
生產廠商:
avx
描述:
IC RESONATOR 433.92MHZ 3.2PF SMD T/R
產品類別:
Logic and Timing|Crystals
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Standard Frequency | 433.92 MHz |
| Frequency Tolerance | ±75 KHz |
| Load Capacitance | 3.2 pF |
| Type | Resonator |
| Maximum Operating Temperature | 85 °C |
| Minimum Operating Temperature | -40 °C |
| Standard Package | Tape & Reel |
| Product Category | Resonators |
| RoHS | RoHS Compliant By Exemption |
| Frequency | 433.92 MHz |
| Tolerance | 75 kHz |
| Series | PARS |
| Termination Style | SMD/SMT |
| Operating Temperature Range | - 40 C to + 85 C |
| Dimensions | 3.8 mm W x 5.5 mm L x 1.5 mm H |
| Packaging | Reel |
| Factory Pack Quantity | 2000 |
| Life | Verify Status with Factory: Lifecycle information is unclear. Obtain a quote to verify the availability of this part number from the manufacturer. |
| Supplier Package | CSMD |
| Standard Package Name | CSMD |
| EU RoHS | Compliant |
| Resonance Frequency | 433.92 |
| Load Capacitance | 3.2 |
| Package Width | 3.8 |
| Mounting | Surface Mount |
| PCB | 4 |
| Package Length | 5.5 |
| Minimum Operating Temperature | -40 |
| Maximum Operating Temperature | 85 |
| Pin Count | 4 |
| Mounting Type | Surface Mount |
| Height | 0.059" (1.50mm) |
| Size / Dimension | 0.217" L x 0.150" W (5.50mm x 3.80mm) |
| Operating Temperature | -40°C ~ 85°C |
| Package/Case | 4-SMD |
| rohs | Lead free / RoHS Compliant |
| Other Names | 478-2117-1 |
| Depth | 1.5 in. |
| Length | 5.5 in. |
| Material | SMT Ceramic (Package) |
| Package Type | 5.5x3.8mm SMD |
| Series Code | PARS |
| Temperature, Operating, Range | -40 to +85 °C |
