SM312LPQD
Sensor; Bipolar NPN/PNP; Photoelectric; 0.4 to 10; LED; 10 to 30 VDC; 1 ms; ABS
廠商型號:
SM312LPQD
芯天下內部編號:
1088-SM312LPQD
生產廠商:
Banner Engineering
描述:
Sensor; Bipolar NPN/PNP; Photoelectric; 0.4 to 10; LED; 10 to 30 VDC; 1 ms; ABS
產品類別:
Automation & Control Gear|Sensors & Transducers|Photoelectric Sensors
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Brand/Series | Mini-Beam? |
| Current,Switching | 150mA |
| Dimensions | 2.10in.Lx1.21in.Hx0.48in.T |
| Function | Proximity |
| Indicator | RedLEDindicator |
| IPRating | IP67 |
| LightSource | LED |
| Material,Body | ABS |
| Material,Cover | Acrylic |
| Material,Lens | Acrylic |
| MountingType | Panel |
| Output | NPN/PNP |
| PrimaryType | Photoelectric |
| Range,Measurement | 3m |
| ResponseTime | 1ms |
| SensingMode | PolarizedRetro-Reflective |
| Standards | ULRecognized,CSACertified,CEApproved |
| Technology | Photoelectric |
| Temperature,Operating | -20to+70°C |
| Termination | 4-WireConnector |
| Voltage,Supply | 30VDC |
