Z0853008PSG
Timers & Support Products 8 MHZ Z8500 SCC
廠商型號:
Z0853008PSG
芯天下內部編號:
803-Z0853008PSG
生產廠商:
ZiLOG
描述:
Timers & Support Products 8 MHZ Z8500 SCC
產品類別:
Semiconductors|Integrated Circuits - ICs|Clock & Timer ICs - Analog|Timers & Support Products
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| RoHS | RoHS Compliant |
| Packaging | Tube |
| Factory Pack Quantity | 10 |
| Mounting Type | Through Hole |
| Standard Package | 10 |
| Supplier Device Package | 40-PDIP |
| Voltage - Supply | 4.75 V ~ 5.25 V |
| Package / Case | 40-DIP (0.620", 15.75mm) |
| Interface | Serial |
| rohs | Lead free / RoHS Compliant |
| Maximum Operating Supply Voltage | 5.25 V |
| Maximum Operating Temperature | +70 °C |
| Minimum Operating Supply Voltage | 4.75 V |
| Minimum Operating Temperature | 0 °C |
| Package Type | DIP |
| PCI Support | No |
| Pin Count | 40 |
| Serial ATA | No |
| Series | Z0853008 |
| Core Size | :- |
| Program Memory Size | :- |
| Supply Voltage Min | :4.75V |
| Supply Voltage Max | :5.25V |
| Digital IC Case Style | :DIP |
| No. of Pins | :40 |
| Operating Temperature Min | :0°C |
| Operating Temperature Max | :70°C |
| MSL | :- |
| SVHC | :No SVHC (20-Jun-2013) |
| Base Number | :8530 |
| Clock Frequency | :8MHz |
| Communication Function | :Serial Communication Controller (SCC) |
| IC Generic Number | :08530 |
| IC Temperature Range | :Commercial |
| Logic Function Number | :8530 |
| Operating Temperature Range | :0°C to +70°C |
| Supply Current | :250mA |
| Supply Voltage Range | :4.75V to 5.25V |
| Termination Type | :Through Hole |
| Weight (kg) | 0.000001 |
| Tariff No. | 85423190 |
相似產品
| 型號 | 廠商 | 描述 | 操作 |
|---|---|---|---|
| Z0853008VSG | ZiLOG | Timers & Support Products 8 MHZ Z8500 SCC | 查看詳情 |
