AFBR-5803TZ
TX/RX Optical Fiber 125MBd 9-Pin
廠商型號:
AFBR-5803TZ
芯天下內部編號:
9-AFBR-5803TZ
生產廠商:
avago technologies

描述:
TX/RX Optical Fiber 125MBd 9-Pin
產品類別:
Communication|Optical Fiber
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
參數類型 | 參數值 |
---|---|
Type | TX/RX |
Mounting | Through Hole |
Wavelength | 1308/1380(Max) nm |
Rise Time | 3/2.2 ns |
Operating Supply Voltage | 3.135 to 3.5|4.75 to 5.25 V |
Standard Package | Rail / Tube |
Product Category | Fiber Optic Transmitters, Receivers, Transceivers |
RoHS | RoHS Compliant |
Product | Transceivers |
Data Rate | 125 Mbps |
Maximum Operating Temperature | + 70 C |
Minimum Operating Temperature | 0 C |
Fiber Type | Multimode |
Factory Pack Quantity | 10 |
Typical Operating Supply Voltage | 3.3|5 |
Emitter Type | LED |
EU RoHS | Compliant |
Maximum Operating Temperature | 70 |
Maximum Data Rate | 125MBd |
Minimum Operating Temperature | 0 |
Rise Time | 3/2.2 |
Connector Type | ST |
Package Height | 24.8 |
Peak Wavelength | 1308/1380(Max) |
Package Width | 12 |
PCB | 9 |
Package Length | 25.4 |
Maximum Operating Supply Voltage | 3.5|5.25 |
Maximum Output Current | 50 |
Minimum Operating Supply Voltage | 3.135|4.75 |
Pin Count | 9 |
Maximum Fall Time | 3/2.2 |
Mounting Type | Through Hole |
Applications | General Purpose |
Voltage - Supply | 3.3V, 5V |
rohs | Lead free / RoHS Compliant |
Connector Shape | Round |
Dimensions | 25.4 x 12 x 24.8mm |
Height | 24.8mm |
Length | 25.4mm |
Number of Pins | 9 |
Peak Transmitter Wavelength | 1380nm |
Receiver Jitter at Maximum Data Rate | 2.14ns |
Transmitter Jitter at Maximum Data Rate | 0.69ns |
Width | 12mm |
Maximum Output Current | 50 mA |
Operating Temp Range | 0C to 70C |
Peak Wavelength | 1380 nm |
Optical Fall Time | 3/2.2 ns |
Optical Rise Time | 3/2.2 ns |
Operating Temperature (Max) | 70C |
Operating Temperature (Min) | 0C |
Data Transfer Rate | 125MBd |
Operating Temperature Classification | Commercial |
Output Current | 0.05 A |
Jitter | 0.69/2.14 ns |
Rad Hardened | No |
Operating Supply Voltage (Typ) | 3.3/5 V |
Operating Supply Voltage (Min) | 3.135/4.75 V |
Operating Supply Voltage (Max) | 3.5/5.25 V |
Optical Fiber Type | TX/RX |
Fibre Optic Applications | :Multimode Fibre Backbone Links, Multimode Fibre Media Converter |
Data Rate Max | :100Mbps |
Supply Voltage | :5V |
Wavelength Typ | :1300nm |
SVHC | :No SVHC (20-Jun-2013) |
External Depth | :39.6mm |
External Length / Height | :12.0mm |
External Width | :25.4mm |
Fibre Type | :Multimode |
Lead Spacing | :2.54mm |
Operating Temperature Max | :70°C |
Operating Temperature Min | :0°C |
Pin Format | :1 x 9 SIL |
Supply Voltage Max | :5.0V |
Supply Voltage Min | :3.3V |
Weight (kg) | 0.014 |
Tariff No. | 85411000 |
