KCDA04-106
Orange double 0.4in SMD 14-seg c-anode
廠商型號:
KCDA04-106
芯天下內部編號:
213-KCDA04-106
生產廠商:
Kingbright
描述:
Orange double 0.4in SMD 14-seg c-anode
產品類別:
Displays & Optoelectronics|Displays & Industrial Monitors|LED Displays
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Character Dimensions | 10.16 x 5.6mm |
| Character Height | 10.16mm |
| Character Width | 5.6mm |
| Colour of Face | Grey |
| Common Connection | Anode |
| Decimal Orientation | Left Side |
| Display Type | 7-Segment |
| External Depth | 3.75mm |
| External Dimensions | 15 x 18.5 x 3.75mm |
| External Height | 15mm |
| External Width | 18.5mm |
| LED Colours | Orange |
| Luminous Intensity | 60000 μcd |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Mounting Type | PCB Surface Mount |
| Number of Characters | 2 |
| Number of Segments | 7 |
| No. of Digits / Alpha | :2 |
| Character Size | :10.16mm |
| LED Colour | :Orange |
| Forward Current If | :30mA |
| Forward Voltage | :2.1V |
| SVHC | :No SVHC (20-Jun-2013) |
| Display Mode | :Reflective |
| Operating Temperature Max | :85°C |
| Operating Temperature Min | :-40°C |
| Operating Temperature Range | :-40°C to +85°C |
| Packaging | :Each |
| Weight (kg) | 0.001309 |
| Tariff No. | 85312020 |
