TPD12S520DBTR
Single Chip HDMI Receiver Port Protection and Interface Device 38-Pin TSSOP T/R
廠商型號:
TPD12S520DBTR
芯天下內部編號:
136-TPD12S520DBTR
生產廠商:
texas instruments
描述:
Single Chip HDMI Receiver Port Protection and Interface Device 38-Pin TSSOP T/R
產品類別:
Interface|Interface Misc
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Package | 38TSSOP |
| Operating Temperature | -40 to 85 °C |
| Standard Package | Tape & Reel |
| Product Category | ESD Suppressors |
| RoHS | RoHS Compliant |
| Channels | 12 Channels |
| Breakdown Voltage | 9 V |
| Package / Case | TSSOP-38 |
| Operating Temperature Range | - 40 C to + 85 C |
| Packaging | Reel |
| Series | TPD12S520 |
| Factory Pack Quantity | 2000 |
| Standard Package Name | TSSOP |
| EU RoHS | Compliant |
| Maximum Operating Temperature | 85 |
| Package Height | 1.05(Max) |
| Mounting | Surface Mount |
| PCB | 38 |
| Package Width | 4.5(Max) |
| Supplier Package | TSSOP |
| Package Length | 9.8(Max) |
| Minimum Operating Temperature | -40 |
| Pin Count | 38 |
| Lead Shape | Gull-wing |
| Mounting Type | Surface Mount |
| Supplier Device Package | 38-TSSOP |
| Applications | Video Equipment |
| Voltage - Supply | 5V |
| Interface | HDMI |
| rohs | Lead free / RoHS Compliant |
| Other Names | 296-23617-1 |
| Dimensions | 9.7 x 4.4 x 1.15mm |
| Height | 1.15mm |
| Length | 9.7mm |
| Maximum Operating Temperature | +85 °C |
| Minimum Operating Temperature | -40 °C |
| Package Type | TSSOP |
| Width | 4.4mm |
| Unit Weight | 0.004374 oz |
| Operating Temperature (Max) | 85C |
| Operating Temperature (Min) | -40C |
| Operating Temperature Classification | Industrial |
| Rad Hardened | No |
| IC Function | :HDMI Receiver Port Protection and Interface Device |
| Brief Features | :- |
| Supply Voltage Min | :5V |
| Supply Voltage Max | :5.5V |
| Operating Temperature Min | :-40°C |
| Operating Temperature Max | :85°C |
| Digital IC Case Style | :TSSOP |
| No. of Pins | :38 |
| MSL | :MSL 2 - 1 year |
| SVHC | :No SVHC (16-Dec-2013) |
| Weight (kg) | 0.000118 |
| Tariff No. | 85423990 |
| Status | ACTIVE |
| Temp (oC) | -40 to 85 |
| Package | Pins | TSSOP?(DBT) | 38 |
| Device Marking | View |
| Package QTY | Carrier | 2000 | LARGE T&R |
| Bi-/Uni-Directional | Uni-Directional |
| New Flag | |
| Functional Diagram | |
| IEC 61000-4-2 Air-Gap | |
| Package Group | TSSOP WQFN |
| Number of Channels | 12 |
| Reference Design | |
| IEC 61000-4-2 Contact | 8 |
| Clamping Voltage | 9 |
| IO Leakage Current | 1000 |
| Datasheet | SLVS640F |
| Special Features | Level Shifter |
| Rating | Catalog |
| TI Design | |
| IO Capacitance | 0.9 |
