VIPER50A-E
Current Mode PWM Controller 700V 1.5A 5-Pin(5+Tab) PENTAWATT
廠商型號:
VIPER50A-E
芯天下內部編號:
390-VIPER50A-E
生產廠商:
stmicroelectronics
描述:
Current Mode PWM Controller 700V 1.5A 5-Pin(5+Tab) PENTAWATT
產品類別:
Power Management|PWM Controllers|Current Mode PWM Controller
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Package | 5PENTAWATT |
| Number of PWM Outputs | 1 |
| Output Current | 1500 mA |
| Output Voltage | 700(Min) V |
| Switching Frequency | 200 kHz |
| Mounting | Through Hole |
| Fall Time | 100 ns |
| Rise Time | 50 ns |
| Standard Package | Rail / Tube |
| Supplier Package | PENTAWATT |
| Standard Package Name | TO-220 |
| EU RoHS | Compliant |
| Control Method | Current Mode PWM Controller |
| Output Voltage | 700(Min) |
| Switching Frequency | 200 |
| Rise Time | 50 |
| On/Off Pin | No |
| Synchronous Pin | No |
| Maximum Operating Supply Voltage | 15 |
| Fall Time | 100 |
| Adjustable Output | No |
| Output Current | 1500 |
| Minimum Operating Supply Voltage | 0 |
| Pin Count | 5 |
| Lead Shape | Through Hole |
| Matchcode | VIPER50A-E |
| T(A) min | -45°C |
| Unit Pack | 50 |
| Standard Leadtime | 15 weeks |
| MOQ | 50 |
| T(A) max | 150°C |
| I(out) | 1.5A |
| Automotive | NO |
| f(s) | 1000000Hz |
| V(in) max | 15V |
| Type | SMPS |
| V(out) | 700V |
| Leadfree Defin. | RoHS-conform |
| Frequency Range | 90kHz ~ 200kHz |
| Supplier Device Package | 5-PENTAWATT |
| Output Isolation | Isolated |
| Packaging | Tube |
| Operating Temperature | 25°C ~ 125°C |
| Voltage - Breakdown | 700V |
| Package / Case | Pentawatt-5 HV (Bent and Staggered Leads) |
| Voltage - Input | 8 V ~ 15 V |
| Power (Watts) | 60W |
| rohs | Lead free / RoHS Compliant |
| Dimensions | 10.4 x 4.8 x 9.2mm |
| Height | 9.2mm |
| Length | 10.4mm |
| Maximum Switching Frequency | 200 kHz |
| Mounting Type | Through Hole |
| Package Type | PENTAWATT |
| Typical Operating Supply Voltage | 0 → 15 V |
| Width | 4.8mm |
| Factory Pack Quantity | 50 |
| Product Category | AC/DC Converters |
| Input / Supply Voltage - Min | 12.6 V |
| Input / Supply Voltage - Max | 13.4 V |
| Mounting Style | Through Hole |
| Duty Cycle - Max | 50 % |
| RoHS | RoHS Compliant |
| Minimum Operating Temperature | - 25 C |
| Supply Current | 12 mA |
| Maximum Operating Temperature | + 125 C |
| Number of Outputs | 1 |
| Switching Freq | 200 KHz |
| Rad Hardened | No |
| Operating Supply Voltage (Max) | 15 V |
| Primary Input Voltage | :15V |
| No. of Outputs | :1 |
| Voltage Regulator Case Style | :Pentawatt |
| No. of Pins | :5 |
| MSL | :- |
| SVHC | :No SVHC (20-Jun-2013) |
| Base Number | :50 |
| Frequency | :100kHz |
| IC Generic Number | :50 |
| Logic Function Number | :50 |
| Power Supply Type | :SMPS |
| Termination Type | :Through Hole |
| Weight (kg) | 0.002 |
| Tariff No. | 85412900 |
