B78108S1105J
Fixed Inductors 1000uH 130mA 14ohms
廠商型號:
B78108S1105J
芯天下內部編號:
125-B78108S1105J
生產廠商:
EPCOS
描述:
Fixed Inductors 1000uH 130mA 14ohms
產品類別:
Passive Components|Inductors|Fixed Inductors
所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。
庫存與訂購
產品參數
| 參數類型 | 參數值 |
|---|---|
| Product Category | Fixed Inductors |
| RoHS | RoHS Compliant |
| Inductance | 1 mH |
| Tolerance | 5 % |
| Maximum DC Current | 130 mA |
| Maximum DC Resistance | 14 Ohms |
| Self Resonant Frequency | 1.6 MHz |
| Q Minimum | 50 |
| Termination Style | Axial |
| Packaging | Reel |
| Factory Pack Quantity | 5000 |
| Part # Aliases | B78108S1105J000 |
| Maximum DC Resistance | 14 |
| Product Length | 11.5 |
| EU RoHS | Compliant |
| Minimum Self Resonant Frequency | 1.6M |
| Maximum DC Current | 130m |
| Lead Style | Axial |
| Product Diameter | 4 |
| Core Material | Ferrite |
| Minimum Quality Factor | 50@252KHz |
| Test Frequency | 100K |
| Type | RF Choke |
| Technology | Bobbin Core |
| Current Rating | 130mA |
| DC Resistance (DCR) | 14 Ohm Max |
| Standard Package | 5,000 |
| Material - Core | Ferrite |
| Frequency - Self Resonant | 1.6MHz |
| Shielding | Unshielded |
| Supplier Device Package | Axial |
| Size / Dimension | 0.157" Dia x 0.362" L (4.00mm x 9.20mm) |
| Mounting Type | Through Hole |
| Q @ Freq | 50 @ 252kHz |
| Frequency - Test | 252kHz |
| Package/Case | Axial |
| rohs | Lead free / RoHS Compliant |
| Other Names | 495-5550-1 |
| Diameter | 4mm |
| Dimensions | 4 Dia. x 11.5mm |
| Length | 11.5mm |
| Maximum Self Resonant Frequency | 1.6MHz |
| Product Range | :EPCOS - B78108S BC Series |
| Inductance Tolerance | :± 5% |
| DC Resistance Max | :14ohm |
| DC Current Rating | :130mA |
| Self Resonant Frequency Min | :1.6MHz |
| Case Dimensions | :4mm x 9.2mm |
| SVHC | :No SVHC (20-Jun-2013) |
| Body Diameter | :4mm |
| External Length / Height | :9.2mm |
| Inductance Measurement Frequency | :0.1MHz |
| Inductor Case Style | :Axial Leaded |
| Inductor Type | :High Frequency / RF |
| Lead Diameter | :0.63mm |
| Lead Length | :25mm |
| No. of Pins | :2 |
| Q Factor | :50 |
| Q Test Frequency | :252kHz |
| Tolerance + | :5% |
| Tolerance - | :5% |
| Weight (kg) | 0.00039 |
| Tariff No. | 85318095 |
| Package / Case | Axial |
