DEBF33D103ZA3B

Cap Ceramic 0.01uF 2000V F -20% to 80% (12 X 5mm) Radial 7.5mm 85°C Bulk

Thumbnail DEBF33D103ZA3B Thumbnail DEBF33D103ZA3B Thumbnail DEBF33D103ZA3B Thumbnail DEBF33D103ZA3B Thumbnail DEBF33D103ZA3B Thumbnail DEBF33D103ZA3B Thumbnail DEBF33D103ZA3B Thumbnail DEBF33D103ZA3B
廠商型號: DEBF33D103ZA3B
芯天下內部編號: 233-DEBF33D103ZA3B
生產廠商:
murata electronics murata electronics
描述: Cap Ceramic 0.01uF 2000V F -20% to 80% (12 X 5mm) Radial 7.5mm 85°C Bulk
產品類別: Capacitor|Capacitor Ceramic Singlelayer
客戶編號:
規格書: 查看PDF
瀏覽次數: 4

所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。

庫存與訂購

庫存: 0
庫存獲取中，請稍候....

產品參數

參數類型 參數值
Package/Case 12(Max) X 5(Max)
Mounting Through Hole
Capacitance Value 0.01 uF
Voltage 2000 Vdc
Tolerance -20 to 80 %
Dielectric F
Lead Pitch For Radial 7.5 mm
Product Diameter 12(Max) mm
Operating Temperature -25 to 85 °C
Termination Style Radial
Product Depth 5(Max) mm
Standard Package Bulk
Product Category Ceramic Disc Capacitors
RoHS RoHS Compliant
Capacitance 0.01 uF
Voltage Rating 2 kV
Operating Temperature Range - 25 C to + 85 C
Product High Voltage Ceramic Disc Capacitors
Capacitance - nF 10 nF
Capacitance - pF 10000 pF
Case Diameter 12 mm
Lead Spacing 7.5 mm
Packaging Bulk
Series DEB
Factory Pack Quantity 3000
Temperature Coefficient / Code F
Lead Diameter 0.6
Type Ceramic Disc
EU RoHS Compliant
Maximum Operating Temperature 85
Product Diameter 12(Max)
Product Depth 5(Max)
Seated Plane Height 15(Max)
Lead Pitch For Radial 7.5
Unit Pack 200
MOQ 200
Industry Aliases DE1207F103Z2K
Subcategory Capacitor Ceramic Singlelayer
Lead Time 70 Days
Mounting Type Through Hole
Voltage - Rated 2000V (2kV)
Lead Style Flat Bent
Temperature Coefficient F
Height - Seated (Max) 0.591" (15.00mm)
Size / Dimension 0.472" Dia (12.00mm)
Applications General Purpose
Other Names 490-4254
Features High Voltage
rohs Lead free / RoHS Compliant
Depth 5mm
Length 12mm
Maximum Operating Temperature +85°C
Minimum Operating Temperature -25°C
Tolerance Minus -20%
Tolerance Plus +80%
Operating Temp Range -25C to 85C
Rad Hardened No
Failure Rate Not Required
Lead Diameter (nom) 0.6 mm
Construction Radial
Tolerance (+ or -) -20% to 80%
Temp Coeff (Dielectric) F
Lead Spacing (nom) 7.5 mm
Mounting Style Through Hole
Package / Case Not Required
Product Length (mm) Not Required mm
Product Depth (mm) 5 mm
Product Height (mm) Not Required mm
Seated Plane Height 15 mm
Size (mm) 12 X 5
Product Diameter (mm) 12 mm
Product Range :MURATA - DEB Series
Capacitance Tolerance :+80%, -20%
Dielectric Characteristic :F
Capacitor Terminals :Radial Leaded
Operating Temperature Min :-25°C
Operating Temperature Max :85°C
SVHC :No SVHC (20-Jun-2013)
Body Diameter :12mm
Weight (kg) 0.0009
Tariff No. 85322300
