ICE40LP1K-CM49

IC FPGA LP 1280LUTS 1.2V 49CBGA

Thumbnail ICE40LP1K-CM49 Thumbnail ICE40LP1K-CM49 Thumbnail ICE40LP1K-CM49 Thumbnail ICE40LP1K-CM49
廠商型號: ICE40LP1K-CM49
芯天下內部編號: 224-ICE40LP1K-CM49
生產廠商:
Lattice Semiconductor Corporation Lattice Semiconductor Corporation
描述: IC FPGA LP 1280LUTS 1.2V 49CBGA
產品類別: Integrated Circuits (ICs)|Embedded - FPGAs (Field Programmable Gate Array)|LP
客戶編號:
規格書: 查看PDF
瀏覽次數: 4

所示圖像僅為示意圖。請從產品數據表中獲得準確的規格。

庫存與訂購

庫存: 0
庫存獲取中，請稍候....

產品參數

參數類型 參數值
Number of LABs/CLBs 160
Mounting Type Surface Mount
Number of Logic Elements/Cells 1280
Standard Package 490
Supplier Device Package 49-CSBGA (3x3)
Total RAM Bits 65536
Operating Temperature -40°C ~ 100°C
Voltage - Supply 1.14 V ~ 1.26 V
Number of I /O 35
Package / Case 49-VFBGA
Dimensions 3 x 3 x 0.9mm
Family Name iCE40 LP
Height 0.9mm
Length 3mm
Maximum Operating Supply Voltage 1.26 V
Maximum Operating Temperature +85 °C
Minimum Operating Supply Voltage 1.14 V
Minimum Operating Temperature -40 °C
Number of Logic Cells 1280
Number of Logic Units 160
Number of RAM Bits 64kbit
Number of Registers 1280
Package Type UCBGA
Pin Count 49
Width 3mm
rohs Compliant
Operating Supply Voltage 1.2 V
Factory Pack Quantity 490
Product iCE40 LP
Number of Logic Array Blocks - LABs 160
Series iCE40LP1K-CM
Number of I/Os 35
Maximum Operating Frequency 533 MHz
Packaging Tray
Number of Gates 1280
Number of Logic Elements 1280
M4K Memory 64 kbit
Mounting Style SMD/SMT
Total Memory 64 kbit
RoHS RoHS Compliant
Logic Cells 1280
Mounting Surface Mount
Operating Temp Range -40C to 85C
Process Technology 40nm
Operating Temperature (Max) 85C
Operating Temperature (Min) -40C
Operating Temperature Classification Industrial
RAM Bits 65536 b
Programmable Yes
# I/Os (Max) 35
Rad Hardened No
Operating Supply Voltage (Typ) 1.2 V
Operating Supply Voltage (Min) 1.14 V
Operating Supply Voltage (Max) 1.26 V
Standard Pack Qty 490
Brand Lattice
